Construction of a circRNA-miRNA-mRNA competitive endogenous RNA network based on microarray data and its correlation with liver injury in a mouse model of autoimmune hepatitis

DOI: 10.12449/JCH250513

  • College of Basic Medical Sciences，Shanxi University of Chinese Medicine，Jinzhong，Shanxi 030619，China

Research funding:

The Construction Project of High-level Traditional Chinese Medicine Key Discipline of National Administration of Traditional Chinese Medicine （2024） (2024);

Key Team of Scientific and Technological Innovation Talents of Shanxi Province with Integrated Traditional Chinese and Western Medicine for Preventing and Treating Rheumatological Diseases (202204051002033);

Special Project with Important Nations of Scientific and Technological Cooperation and Exchange of Shanxi Province (202104041101013);

Youth Science and Technology Research Fund of Applied Basic Research Program of Shanxi Province (202203021222272);

Scientific Research Project of Administration of Traditional Chinese Medicine in Shanxi Province (2024ZYYAD008);

Science and Technology Innovation Project of Shanxi University of Chinese Medicine (2022TD2003);

Key Laboratory of Rheumatological and Immunological Diseases Treated by Integrated Chinese and Western Medicine (zyyyjs2024021)

More Information
  • Corresponding author: LIU Yang， liuyang1980@sxtcm.edu.cn （ORCID： 0000-0002-6627-5002）
  • Received Date: 2024-09-13
  • Accepted Date: 2024-11-27
  • Published Date: 2025-05-25
    Abstract
  •   Objective  To construct a circRNA-miRNA-mRNA competitive endogenous RNA （ceRNA） network， to investigate its potential regulatory mechanism in a mouse model of autoimmune hepatitis （AIH） induced by concanavalin A （ConA）， and to verify the association between the expression of key genes and liver injury.  Methods  High-throughput data were used to identify differentially expressed circRNAs， miRNAs， and mRNAs， and the Pearson correlation analysis and the Miranda program were used to predict the pairing relationships between miRNAs and mRNAs/circRNAs and construct a ceRNA network. The gene ontology and Kyoto Encyclopedia of Genes and Genomes enrichment analyses were performed for the differentially expressed genes in the network. A total of 12 specific pathogen-free male C57BL/6 mice were divided into control group and model group using a random number table， with 6 mice in each group. The mice in the model group were given injection of ConA via the caudal vein to establish a mouse model of AIH， and those in the control group were given injection of normal saline. The methods of qRT-PCR and Western blot were used to validate the expression levels of circ_0001577， miR-7055-3p， and Akt3. The serum levels of alanine aminotransferase （ALT） and aspartate aminotransferase （AST） were measured， as well as the content of malondialdehyde （MDA） and nitric oxide （NO） in liver tissue， and their correlation with gene expression was analyzed. The independent-samples t test was used for comparison of continuous data between two groups， and the Spearman correlation analysis was used to investigate the correlation between gene expression levels and liver injury indicators.  Results  A ceRNA network containing 5 795 circRNA-miRNA-mRNA pairings was constructed， and circ_0001577 was identified as the central gene. Compared with the control group， the model group had significant increases in the expression levels of circ_0001577 and Akt3 and a significant reduction in the expression of miR-7055-3p （all P<0.05）， and circ_0001577 was positively correlated with Akt3 （r=0.861， P<0.001）， while miR-7055-3p was negatively correlated with circ_0001577 and Akt3 （r=-0.644 and -0.855， both P<0.05）. Compared with the control group， the model group had a significantly higher protein expression level of Akt3 in the liver （1.04±0.10 vs 0.72±0.06， t=-6.49， P=0.001）， which was positively correlated with circ_0001577 （r=0.579， P=0.048） and was negatively correlated with miR-7055-3p （r=-0.891， P<0.001）. Compared with the control group， the model group had significant increases in the serum levels of ALT and AST and the content of MDA and NO in liver tissue （all P<0.05）， and these liver injury indicators were positively correlated with circ_0001577 and Akt3 （r=0.849， 0.865， 0.811， 0.801； 0.889， 0.954， 0.938， and 0.961， all P<0.05） and were negatively correlated with miR-7055-3p （r=-0.687， -0.818， -0.833， and -0.870， all P<0.05）； in addition， they were positively correlated with the protein expression level of Akt3 （r=0.648， 0.796， 0.848， and 0.860， all P<0.05）.  Conclusion  This study shows that circ_0001577 promotes the expression of Akt3 by competitively adsorbing miR-7055-3p and relieving the inhibition of Akt3， thereby participating in the development and progression of AIH.



    • FullText(HTML)
  • loading
    • References(37)
  • [1]
    European Association for the Study of the Liver. EASL clinical practice guidelines: Autoimmune hepatitis[J]. J Hepatol, 2015, 63( 4): 971- 1004. DOI: 10.1016/j.jhep.2015.06.030.
    [2]
    DALEKOS GN, KOSKINAS J, PAPATHEODORIDIS GV. Hellenic association for the study of the liver clinical practice guidelines: Autoimmune hepatitis[J]. Ann Gastroenterol, 2019, 32( 1): 1- 23. DOI: 10.20524/aog.2018.0330.
    [3]
    KOMORI A. Recent updates on the management of autoimmune hepatitis[J]. Clin Mol Hepatol, 2021, 27( 1): 58- 69. DOI: 10.3350/cmh.2020.0189.
    [4]
    WANG HX, LIU M, WENG SY, et al. Immune mechanisms of Concanavalin A model of autoimmune hepatitis[J]. World J Gastroenterol, 2012, 18( 2): 119- 125. DOI: 10.3748/wjg.v18.i2.119.
    [5]
    FLOREANI A, RESTREPO-JIMÉNEZ P, SECCHI MF, et al. Etiopathogenesis of autoimmune hepatitis[J]. J Autoimmun, 2018, 95: 133- 143. DOI: 10.1016/j.jaut.2018.10.020.
    [6]
    TANAKA A. Autoimmune hepatitis: 2019 update[J]. Gut Liver, 2020, 14( 4): 430- 438. DOI: 10.5009/gnl19261.
    [7]
    LIU Y, LI ZC, HAO JH, et al. Circular RNAs associated with a mouse model of concanavalin A-induced autoimmune hepatitis: Preliminary screening and comprehensive functional analysis[J]. FEBS Open Bio, 2020, 10( 11): 2350- 2362. DOI: 10.1002/2211-5463.12981.
    [8]
    SALZMAN J. Circular RNA expression: Its potential regulation and function[J]. Trends Genet, 2016, 32( 5): 309- 316. DOI: 10.1016/j.tig.2016.03.002.
    [9]
    ZHANG Y, ZHANG XO, CHEN T, et al. Circular intronic long noncoding RNAs[J]. Mol Cell, 2013, 51( 6): 792- 806. DOI: 10.1016/j.molcel.2013.08.017.
    [10]
    HE L, MAN CF, XIANG SY, et al. Circular RNAs’ cap-independent translation protein and its roles in carcinomas[J]. Mol Cancer, 2021, 20( 1): 119. DOI: 10.1186/s12943-021-01417-4.
    [11]
    DONG ZR, KE AW, LI T, et al. CircMEMO1 modulates the promoter methylation and expression of TCF21 to regulate hepatocellular carcinoma progression and sorafenib treatment sensitivity[J]. Mol Cancer, 2021, 20( 1): 75. DOI: 10.1186/s12943-021-01361-3.
    [12]
    QU SB, YANG XS, LI XL, et al. Circular RNA: A new star of noncoding RNAs[J]. Cancer Lett, 2015, 365( 2): 141- 148. DOI: 10.1016/j.canlet.2015.06.003.
    [13]
    ZHANG MY, WANG JB, ZHU ZW, et al. Differentially expressed circular RNAs in systemic lupus erythematosus and their clinical significance[J]. Biomed Pharmacother, 2018, 107: 1720- 1727. DOI: 10.1016/j.biopha.2018.08.161.
    [14]
    YANG X, LI J, WU Y, et al. Aberrant dysregulated circular RNAs in the peripheral blood mononuclear cells of patients with rheumatoid arthritis revealed by RNA sequencing: Novel diagnostic markers for RA[J]. Scand J Clin Lab Invest, 2019, 79( 8): 551- 559. DOI: 10.1080/00365513.2019.1674004.
    [15]
    LIU Y, CHEN H, HAO JH, et al. Characterization and functional prediction of the microRNAs differentially expressed in a mouse model of concanavalin A-induced autoimmune hepatitis[J]. Int J Med Sci, 2020, 17( 15): 2312- 2327. DOI: 10.7150/ijms.47766.
    [16]
    LIU Y, CHEN H, HAO JH, et al. Microarray-based transcriptional profiling of a mouse model of autoimmune hepatitis[J]. FEBS Open Bio, 2020, 10( 10): 2040- 2054. DOI: 10.1002/2211-5463.12953.
    [17]
    WANG HY, RADOMSKA HS, PHELPS MA, et al. Replication study: Coding-independent regulation of the tumor suppressor PTEN by competing endogenous mRNAs[J]. eLife, 2020, 9: e56651. DOI: 10.7554/eLife.56651.
    [18]
    PHELPS M, COSS C, WANG HY, et al. Registered report: Coding-independent regulation of the tumor suppressor PTEN by competing endogenous mRNAs[J]. eLife, 2016, 5: e12470. DOI: 10.7554/eLife.12470.
    [19]
    LIU K, YAN ZM, LI YC, et al. Linc2GO: A human LincRNA function annotation resource based on ceRNA hypothesis[J]. Bioinformatics, 2013, 29( 17): 2221- 2222. DOI: 10.1093/bioinformatics/btt361.
    [20]
    RITCHIE ME, PHIPSON B, WU D, et al. Limma powers differential expression analyses for RNA-sequencing and microarray studies[J]. Nucleic Acids Res, 2015, 43( 7): e47. DOI: 10.1093/nar/gkv007.
    [21]
    The Gene Ontology Consortium. The gene ontology resource: 20 years and still GOing strong[J]. Nucleic Acids Res, 2019, 47( D1): D330- D338. DOI: 10.1093/nar/gky1055.
    [22]
    MI HY, HUANG XS, MURUGANUJAN A, et al. PANTHER version 11: Expanded annotation data from Gene Ontology and Reactome pathways, and data analysis tool enhancements[J]. Nucleic Acids Res, 2017, 45( D1): D183- D189. DOI: 10.1093/nar/gkw1138.
    [23]
    YANG J, WANG B, WANG Y, et al. Exosomes derived from adipose mesenchymal stem cells carrying miRNA-22-3p promote schwann cells proliferation and migration through downregulation of PTEN[J]. Dis Markers, 2022, 2022: 7071877. DOI: 10.1155/2022/7071877.
    [24]
    JU J, LI XM, ZHAO XM, et al. Circular RNA FEACR inhibits ferroptosis and alleviates myocardial ischemia/reperfusion injury by interacting with NAMPT[J]. J Biomed Sci, 2023, 30( 1): 45. DOI: 10.1186/s12929-023-00927-1.
    [25]
    ASHWAL-FLUSS R, MEYER M, PAMUDURTI NR, et al. circRNA biogenesis competes with pre-mRNA splicing[J]. Mol Cell, 2014, 56( 1): 55- 66. DOI: 10.1016/j.molcel.2014.08.019.
    [26]
    TAY Y, RINN J, PANDOLFI PP. The multilayered complexity of ceRNA crosstalk and competition[J]. Nature, 2014, 505( 7483): 344- 352. DOI: 10.1038/nature12986.
    [27]
    PASQUINELLI AE. MicroRNAs and their targets: Recognition, regulation and an emerging reciprocal relationship[J]. Nat Rev Genet, 2012, 13( 4): 271- 282. DOI: 10.1038/nrg3162.
    [28]
    HANSEN TB, JENSEN TI, CLAUSEN BH, et al. Natural RNA circles function as efficient microRNA sponges[J]. Nature, 2013, 495( 7441): 384- 388. DOI: 10.1038/nature11993.
    [29]
    SALMENA L, POLISENO L, TAY Y, et al. A ceRNA hypothesis: The Rosetta Stone of a hidden RNA language?[J]. Cell, 2011, 146( 3): 353- 358. DOI: 10.1016/j.cell.2011.07.014.
    [30]
    YANG N, WANG L, CHEN TX, et al. ZNF521 which is downregulated by miR-802 suppresses malignant progression of hepatocellular carcinoma through regulating Runx2 expression[J]. J Cancer, 2020, 11( 19): 5831- 5839. DOI: 10.7150/jca.45190.
    [31]
    HAO PY, WAXMAN DJ. Functional roles of sex-biased, growth hormone-regulated microRNAs miR-1948 and miR-802 in young adult mouse liver[J]. Endocrinology, 2018, 159( 3): 1377- 1392. DOI: 10.1210/en.2017-03109.
    [32]
    SEOK S, SUN H, KIM YC, et al. Defective FXR-SHP regulation in obesity aberrantly increases miR-802 expression, promoting insulin resistance and fatty liver[J]. Diabetes, 2021, 70( 3): 733- 744. DOI: 10.2337/db20-0856.
    [33]
    ZHAO XY, LI SJ, WANG Z, et al. miR-101-3p negatively regulates inflammation in systemic lupus erythematosus via MAPK1 targeting and inhibition of the NF-κB pathway[J]. Mol Med Rep, 2021, 23( 5): 359. DOI: 10.3892/mmr.2021.11998.
    [34]
    YAO YF, WANG H, XI XQ, et al. miR-150 and SRPK1 regulate AKT3 expression to participate in LPS-induced inflammatory response[J]. Innate Immun, 2021, 27( 4): 343- 350. DOI: 10.1177/17534259211018800.
    [35]
    SHI JS, JIANG K, LI ZD. miR-145 ameliorates neuropathic pain via inhibiting inflammatory responses and mTOR signaling pathway by targeting Akt3 in a rat model[J]. Neurosci Res, 2018, 134: 10- 17. DOI: 10.1016/j.neures.2017.11.006.
    [36]
    LOHSE AW, KÖGEL M, MEYER ZUM BÜSCHENFELDE KH. Evidence for spontaneous immunosuppression in autoimmune hepatitis[J]. Hepatology, 1995, 22( 2): 381- 388.
    [37]
    CUETO-SANCHEZ A, NIU H, DEL CAMPO-HERRERA E, et al. Lymphocyte profile and immune checkpoint expression in drug-induced liver injury: An immunophenotyping study[J]. Clin Pharmacol Ther, 2021, 110( 6): 1604- 1612. DOI: 10.1002/cpt.2423.
