肝血管畸形的诊断和治疗

摘要: 肝血管畸形是一类以肝内动脉、静脉或门静脉系统结构异常为特征的先天性或获得性疾病，临床上可表现为高动力循环症、门静脉高压症和门腔分流并发症。该类疾病的发病率较低，临床表现缺乏特异性，尤其易与肝硬化门静脉高压症相混淆，从而导致诊断与治疗的延迟。本文重点介绍肝血管畸形所致的常见临床表现及其鉴别诊断，并阐述3种典型的肝血管畸形疾病，旨在为临床诊治提供思路和参考。
- 肝血管畸形 /
- 病理状态，体征和症状 /
- 诊断 /
- 治疗学
Abstract: Hepatic vascular malformations are a group of congenital or acquired disorders characterized by structural abnormalities of the intrahepatic arterial， venous， or portal venous systems， with the clinical manifestations of hyperdynamic circulation， portal hypertension， and complications of portosystemic shunting. Due to the low incidence rate and nonspecific clinical manifestations of such disorders， they are easily confused with cirrhotic portal hypertension， leading to the delay in diagnosis and treatment. This article introduces the common clinical manifestations and differential diagnosis of hepatic vascular malformations and elaborates on three typical types of hepatic vascular malformations， in order to provide ideas and references for clinical diagnosis and treatment.
- Hepatic Vascular Malformation /
- Pathological Conditions， Signs and Symptoms /
- Diagnosis /
- Therapeutics

HTML全文

注：动脉期肝动脉扩张，肝静脉早显，多发胆管扩张及胆汁瘤。

图 1 肝血管畸形患者的三期CT血管造影（动脉期）

Figure 1. Triphasic CT angiography （arterial phase） in a patient with hepatic vascular malformations

下载: 全尺寸图片幻灯片

注：动脉期门静脉早显。

图 2 HAPF患者CT影像

Figure 2. CT image of a patient with hepatic artery-portal fistula

下载: 全尺寸图片幻灯片

注： a， Ⅰa型； b， Ⅰb型； c， Ⅱ型；IVC，下腔静脉；SV，脾静脉；SMV，肠系膜上静脉；PV，门静脉；SHUNT，分流道/分流血管；CEPS，先天性肝外门体分流。

图 3 经典的CEPS分类

Figure 3. Classic classification of CEPS

下载: 全尺寸图片幻灯片

表 1 肝动静脉畸形鉴别诊断

Table 1. Differential diagnosis of hepatic arteriovenous malformations

项目	肝动脉-肝静脉畸形	肝动脉-门静脉瘘
临床表现	高动力循环	门静脉高压
影像学	动脉期肝静脉早显；肝动脉、肝静脉迂曲扩张；有时伴胆管扩张	动脉期门静脉早显；肝动脉及门静脉扩张；常合并门静脉血栓
合并症和周边表现	高输出量心衰；腹痛“窃血”症状：胆管缺血、肠道缺血	腹水；食管胃底静脉曲张；门静脉血栓
常见病因	遗传性出血性毛细血管扩张症	原发性：基因突变；继发性：外伤、肝硬化、肝癌和化疗药使用
治疗方式	无症状者观察；有症状者针对并发症处理；肝移植	药物及对症治疗；介入栓塞/分流；肝移植

下载: 导出CSV

表 2 门-体静脉分流及其鉴别

Table 2. Portosystemic shunt and its differential diagnosis

项目	先天性肝内门体分流	先天性肝外门体分流（Abernethy畸形）	自发性门体分流
临床表现	无症状	可无症状或仅轻度肝功能异常，直至出现门体分流相关的严重并发症	继发于肝硬化门静脉高压
合并症	无	肝性脑病、肺动脉高压、肝肺综合征、肝细胞癌或肝细胞腺瘤	肝性脑病、腹腔积液、食管胃底静脉曲张
发病年龄	婴儿发病<2岁自发闭合	常于20岁左右诊断，但也有部分患者在50岁后仍无症状^［4］	中年及以后发病
病理特点	不易合并恶性肿瘤	典型表现是门静脉分支缺如或发育不良，并伴有肝窦充血和动脉分支粗大^［5-6］	肝硬化病史及病理表现

下载: 导出CSV

参考文献(27)

[1]	KELLY C, BUSCARINI E, MANFREDI G, et al. Hepatic manifestations of hereditary haemorrhagic telangiectasia[J]. Liver Int, 2024, 44( 9): 2220- 2234. DOI: 10.1111/liv.16008.
[2]	ZENG HJ, TANG SH, QIN S, et al. Progress in the clinical diagnosis and treatment of hepatic vascular diseases[J]. Chin J Hepatol, 2020, 28( 11): 977- 980. DOI: 10.3760/cma.j.cn501113-20200417-00194. 曾海军, 汤善宏, 秦森, 等. 肝血管系统疾病临床诊治进展[J]. 中华肝脏病杂志, 2020, 28( 11): 977- 980. DOI: 10.3760/cma.j.cn501113-20200417-00194.
[3]	SHI HT, LU XL. Portal vein thrombosis and hepatic arterio-portal fistula: A re-conceptualization of the diagnosis and treatment[J]. J Pract Hepatol, 2023, 26( 2): 160- 163. DOI: 10.3969/j.issn.1672-5069.2023.02.003. 史海涛, 鲁晓岚. 门静脉血栓及肝动脉-门静脉瘘诊治再认识[J]. 实用肝脏病杂志, 2023, 26( 2): 160- 163. DOI: 10.3969/j.issn.1672-5069.2023.02.003.
[4]	BAIGES A, TURON F, SIMÓN-TALERO M, et al. Congenital extrahepatic portosystemic shunts(abernethy malformation): An international observational study[J]. Hepatology, 2020, 71( 2): 658- 669. DOI: 10.1002/hep.30817.
[5]	MURRAY CP, YOO SJ, BABYN PS. Congenital extrahepatic portosystemic shunts[J]. Pediatr Radiol, 2003, 33( 9): 614- 620. DOI: 10.1007/s00247-003-1002-x.
[6]	MATSUURA T, TAKAHASHI Y, YANAGI Y, et al. Surgical strategy according to the anatomical types of congenital portosystemic shunts in children[J]. J Pediatr Surg, 2016, 51( 12): 2099- 2104. DOI: 10.1016/j.jpedsurg.2016.09.046.
[7]	BINKO MA, ANDRASKA EA, REITZ KM, et al. The natural history of portal venous system aneurysms[J]. J Vasc Surg Venous Lymphatic Disord, 2025, 13( 3): 102163. DOI: 10.1016/j.jvsv.2024.102163.
[8]	KURTCEHAJIC A, ZEREM E, ALIBEGOVIC E, et al. Portal vein aneurysm-etiology, multimodal imaging and current management[J]. World J Clin Cases, 2023, 11( 4): 725- 737. DOI: 10.12998/wjcc.v11.i4.725.
[9]	AHMED O, OHMAN JW, VACHHARAJANI N, et al. Feasibility and safety of non-operative management of portal vein aneurysms: A thirty-five year experience[J]. Hpb, 2021, 23( 1): 127- 133. DOI: 10.1016/j.hpb.2020.05.006.
[10]	PARK SO, WANKHEDE M, LEE YJ, et al. Real-time imaging of de novo arteriovenous malformation in a mouse model of hereditary hemorrhagic telangiectasia[J]. J Clin Invest, 2009, 119( 11): 3487- 3496. DOI: 10.1172/jci39482.
[11]	BUSCARINI E, DANESINO C, OLIVIERI C, et al. Doppler ultrasonographic grading of hepatic vascular malformations in hereditary hemorrhagic telangiectasia- results of extensive screening[J]. Ultraschall Med, 2004, 25( 5): 348- 355. DOI: 10.1055/s-2004-813549.
[12]	MEMEO M, STABILE IANORA AA, SCARDAPANE A, et al. Hepatic involvement in hereditary hemorrhagic telangiectasia:[J]. Abdom Imag, 2004, 29( 2): 211- 220. DOI: 10.1007/s00261-003-0101-3.
[13]	BUSCARINI E, LEANDRO G, CONTE D, et al. Natural history and outcome of hepatic vascular malformations in a large cohort of patients with hereditary hemorrhagic teleangiectasia[J]. Dig Dis Sci, 2011, 56( 7): 2166- 2178. DOI: 10.1007/s10620-011-1585-2.
[14]	European Association for the Study of the Liver. EASL clinical practice guidelines: Vascular diseases of the liver[J]. J Hepatol, 2016, 64( 1): 179- 202. DOI: 10.1016/j.jhep.2015.07.040.
[15]	SHOVLIN CL, GUTTMACHER AE, BUSCARINI E, et al. Diagnostic criteria for hereditary hemorrhagic telangiectasia(Rendu-Osler-Weber syndrome)[J]. Am J Med Genet, 2000, 91( 1): 66- 67. DOI: 3.0.co;2-p">10.1002/(sici)1096-8628(20000306)91: 1<66:: aid-ajmg12>3.0.co;2-p.
[16]	FAUGHNAN ME, MAGER JJ, HETTS SW, et al. Second international guidelines for the diagnosis and management of hereditary hemorrhagic telangiectasia[J]. Ann Intern Med, 2021, 174( 7): 1035- 1036. DOI: 10.7326/l21-0067.
[17]	BUSCARINI E, BOTELLA LM, GEISTHOFF U, et al. Safety of thalidomide and bevacizumab in patients with hereditary hemorrhagic telangiectasia[J]. Orphanet J Rare Dis, 2019, 14( 1): 28. DOI: 10.1186/s13023-018-0982-4.
[18]	AL-SAMKARI H. Systemic antiangiogenic therapies for bleeding in hereditary hemorrhagic telangiectasia: A practical, evidence-based guide for clinicians[J]. Semin Thromb Hemost, 2022, 48( 5): 514- 528. DOI: 10.1055/s-0042-1743467.
[19]	DUPUIS-GIROD S, GINON I, SAURIN JC, et al. Bevacizumab in patients with hereditary hemorrhagic telangiectasia and severe hepatic vascular malformations and high cardiac output[J]. JAMA, 2012, 307( 9): 948- 955. DOI: 10.1001/jama.2012.250.
[20]	NING SL, XU YF, LU WD, et al. Laparoscopic double hepatic artery banding/ligation for patients with hepatic hereditary haemorrhagic telangiectasia(HHHT)[J]. EJVES Vasc Forum, 2023, 60: 73- 76. DOI: 10.1016/j.ejvsvf.2023.09.007.
[21]	LI LL, YU SP. Classification and treatment progress of hepatic artery-portal vein fistula[J]. J Pract Med Imag, 2014, 15( 4): 286- 288. 李玲玲, 于世平. 肝动脉-门静脉瘘的分类及治疗进展[J]. 实用医学影像杂志, 2014, 15( 4): 286- 288.
[22]	European Association for the Study of the Liver. EASL Clinical Practice Guidelines on vascular diseases of the liver[J]. J Hepatol, 2026, 84( 2): 399- 456. DOI: 10.1016/j.jhep.2025.08.001.
[23]	CITONE M, ANNESE A, GABBANI G, et al. Hepatic barrage to high-flow, intra-hepatic arteroportal fistulas requiring combined interventional approach[J]. BJR\|Case Rep, 2025, 11( 4): uaaf034. DOI: 10.1093/bjrcr/uaaf034.
[24]	HOWARD ER, DAVENPORT M. Congenital extrahepatic portocaval shunts: The Abernethy malformation[J]. J Pediatr Surg, 1997, 32( 3): 494- 497. DOI: 10.1016/s0022-3468(97)90614-x.
[25]	Committee on Liver Diseases(Integrated Traditional Chinese and Western Medicine), China Research Hospital Association; Committee on Interventional Medicine, China Research Hospital Association; Branch for Multidisciplinary Diagnosis and Treatment of Portal Hypertension, Beijing Medical Doctor Association. Expert consensus on clinical practice for the diagnosis and treatment of hepatic vascular diseases(2026 edition)[J]. J Clin Hepatol, 2026, 42( 1): 47- 65. DOI: 10.12449/JCH260107. 中国研究型医院学会肝病(中西医结合)专业委员会, 中国研究型医院学会介入医学专业委员会, 北京医师协会门静脉高压症多学科诊治医师分会. 肝脏血管性疾病诊治临床实践专家共识(2026年版)[J]. 临床肝胆病杂志, 2026, 42( 1): 47- 65. DOI: 10.12449/JCH260107.
[26]	RAJESWARAN S, JOHNSTON A, GREEN J, et al. Abernethy malformations: Evaluation and management of congenital portosystemic shunts[J]. J Vasc Interv Radiol, 2020, 31( 5): 788- 794. DOI: 10.1016/j.jvir.2019.08.007.
[27]	CHOCARRO G, AMESTY MV, ENCINAS JL, et al. Congenital portosystemic shunts: Clinic heterogeneity requires an individual management of the patient[J]. Eur J Pediatr Surg, 2016, 26( 1): 74- 80. DOI: 10.1055/s-0035-1566097.
